Solving ODEs#

Differential Equations#

Differential equations involve derivatives of functions
- Ordinary differential equations (ODEs) involve only derivates of one variable
- Partial differential equations (PDEs) involve partial derivatives

General form of ODE:

\[ \frac{d^nf(x)}{dx^n} = F\left( x, f(x), f'(x), f''(x), \cdots , f^{n-1}(x) \right) \]

$F$ is some arbitrary function in terms $x$, $f(x)$, and its derivatives
$n$ is referred to as the order of the equation

Classifications of ODEs based on:
- Order - refers to highest derivative in equation
- Linearity
  - Linear ODEs - derivatives are only raised to first power (aka linear system of derivatives)
  - Non-linear ODEs
- Homogeneity
  - Homogenous - each term involves $f(x)$ or its derivatives
    - $f(x) = 0$ is a trivial solution
  - Inhomogeneous - includes a non-zero term that does not include $f(x)$ or its derivatatives
    - No trivial solution

Examples
- Linear, second order homogeneous ODE: $f'' + xf' - x^2f = 0$
- Linear, first order inhomogeneous ODE: $f' + f = x$
- Nonlinear, third order inhomogenous ODE: $ f''' + xf^2 = cos(x)$

Ordinary Differential Equations#

Any ODE has a general solution and a particular solution
- General solution is any $f_g(x)$ that satisfies the ODE
- Particular solution is a specific $f_p(x)$ that satisfies the ODE and $n$ explicitly known values of the solution or its derivatives at some points
- Typically, we are interested in the particular solution

Example: $ \frac{d^2 f}{dx^2}=0$

The general solution is $f_g(x)=a_1 x + a_0$
- $a_0$ and $a_1$ are arbitrary constants

To get the particular solution, the function and its derivative at one or two points needs to be specified

Initial value problems (IVPs)
- The value of the function and its derivatives is specified at a point – referred to as the initial conditions
- E.g., motion of a projectile: the initial position and velocity are required to solve the motion of the body w.r.t. time $t$

Boundary value problems (BVPs)
- The value of the function or its derivative is specified at the boundaries of the problem domain known as the boundary conditions
- E.g., heat transfer across a rod – one of temperature or heat flux needs to be specified at each end of the rod

Initial Value Problems#

General form of 1st order IVP: $\frac{du}{dt} = g(u,t)$
- Given some initial condition: $u(t=t_0) = u_0$

Solution procedure:

Discretize the problem domain into n intervales of time (not necessarily evenly spaced)

Use a finite difference approximation for the 1st order derivative to convert the differential equation into a difference equation at each time step

Solve the resulting difference equation at each point in the discretized problem domain

This results in a linear system of equations with the unknowns: $u_1, u_2, \cdots, u_n$
- The linear system may be coupled depending on the choice of finite difference approximation, in which case a linear solver should be used to solve it

Discretization methods for initial value problems (IVPs)
- Euler methods
- Runge-Kutta methods
  - Methods more sophisticated than the Euler methods
  - Use multiple points to approximate the derivative (e.g., RK4 method uses 4 points)
  - scipy.integrate.solve_ivp uses RK4(5) method to solve IVPs
  - Euler methods can be considered as special cases of the RK methods
- Predictor-corrector methods – add a correction step to a prediction step
  - Prediction step is realized via Euler methods or a similar method

Explicit methods typically lead to decoupled equations
- Easy to implement
- Typically, less or conditionally stable
  - Stability refers to the ability of the algorithm to keep the error bounded

Implicit methods lead to coupled linear system of equations
- Computationally expensive
- Can be unconditionally stable

Forward Euler Method#

Uses the forward difference to approximatge the 1st order derivative

\[ \frac{du}{dt} = g(u,t) \]

\[ \implies \frac{u(t+\Delta t) - u(t)}{\Delta t} \approx g(u,t) \]

\[ \implies u(t + \Delta t) \approx u(t) + \Delta t g(u,t) \]

Let the discretized problem domain be: ${t_0, t_1, t_2, \cdots, t_n}$ and the initial condition be $u(t_0 ) = u_0$

\[ u_1 \approx u_0 + (t_1 - t_0)g(u_0,t_0) \]

\[ u_2 \approx u_1 + (t_2 - t_1)g(u_1,t_1) \]

In general:

\[ u_{i+1} \approx u_{i} + (t_{i+1} - t_{i})g(u_i,t_i) \]

The value of the function at time $t_{i+1}$ can be explicitly computed in terms of known quantities – thus the name explicit Euler method

Example#

A ball is thrown upwards with an initial velocity of 10 m/s. How much time does it take for the ball to reach its maximum height.
This system can be modeled by the equation $a(t) = \dot{v}(t) = -g$ with initial condition $v(0) = 10 m/s$

Numerical solution using forward Euler method

\[ \dot{v}(t_i) \approx \frac{v(t_{i+1}) - v(t_i)}{\Delta t} = -g \]

\[ \implies v(t_{i+1}) = -g \Delta t + v(t_i) \]

Repeated application of this formula will starting with $t_i = 0$ will give us the velocities at other times $t_1, t_2, t_3, \cdots$

%matplotlib widget
import numpy as np
import matplotlib.pyplot as plt

# Problem parameters
v0 = 10  # m/s
g = 9.81 # m/s2

# exact solution
t_exact = v0/g

print(t_exact)

---------------------------------------------------------------------------
ModuleNotFoundError                       Traceback (most recent call last)
Cell In[1], line 1
----> 1 get_ipython().run_line_magic('matplotlib', 'widget')
      2 import numpy as np
      3 import matplotlib.pyplot as plt

File /opt/hostedtoolcache/Python/3.11.9/x64/lib/python3.11/site-packages/IPython/core/interactiveshell.py:2480, in InteractiveShell.run_line_magic(self, magic_name, line, _stack_depth)
   2478     kwargs['local_ns'] = self.get_local_scope(stack_depth)
   2479 with self.builtin_trap:
-> 2480     result = fn(*args, **kwargs)
   2482 # The code below prevents the output from being displayed
   2483 # when using magics with decorator @output_can_be_silenced
   2484 # when the last Python token in the expression is a ';'.
   2485 if getattr(fn, magic.MAGIC_OUTPUT_CAN_BE_SILENCED, False):

File /opt/hostedtoolcache/Python/3.11.9/x64/lib/python3.11/site-packages/IPython/core/magics/pylab.py:103, in PylabMagics.matplotlib(self, line)
     98     print(
     99         "Available matplotlib backends: %s"
    100         % _list_matplotlib_backends_and_gui_loops()
    101     )
    102 else:
--> 103     gui, backend = self.shell.enable_matplotlib(args.gui.lower() if isinstance(args.gui, str) else args.gui)
    104     self._show_matplotlib_backend(args.gui, backend)

File /opt/hostedtoolcache/Python/3.11.9/x64/lib/python3.11/site-packages/IPython/core/interactiveshell.py:3665, in InteractiveShell.enable_matplotlib(self, gui)
   3662     import matplotlib_inline.backend_inline
   3664 from IPython.core import pylabtools as pt
-> 3665 gui, backend = pt.find_gui_and_backend(gui, self.pylab_gui_select)
   3667 if gui != None:
   3668     # If we have our first gui selection, store it
   3669     if self.pylab_gui_select is None:

File /opt/hostedtoolcache/Python/3.11.9/x64/lib/python3.11/site-packages/IPython/core/pylabtools.py:338, in find_gui_and_backend(gui, gui_select)
    321 def find_gui_and_backend(gui=None, gui_select=None):
    322     """Given a gui string return the gui and mpl backend.
    323
    324     Parameters
   (...)
    335     'WXAgg','Qt4Agg','module://matplotlib_inline.backend_inline','agg').
    336     """
--> 338     import matplotlib
    340     if _matplotlib_manages_backends():
    341         backend_registry = matplotlib.backends.registry.backend_registry

ModuleNotFoundError: No module named 'matplotlib'

# numerical solution
dt = 0.1                # Time step
t = np.arange(0, 2, dt)  # Time domain
v = np.zeros_like(t)     # Initialize velocity array
v[0] = v0                # Set initial velocity

# Compute velocity at discrete time points
for i in range(len(v)-1):
    # Forward Euler formula
    v[i+1] = v[i] - g*dt

# Time of ascent
# Approximated as the time at which the velocity changes sign
t_asc = t[np.argmax(v0-np.abs(v))] + 0.5*dt
print(t_asc)

1.05

fig, ax = plt.subplots()
ax.plot(t, v, '.k', label='Fwd Euler')
ax.plot(t, np.zeros_like(t), '--m')
ax.set(xlabel='t (s)', ylabel='v (m/s)')

Backward Euler Method#

Uses the backward difference to approximatge the 1st order derivative

\[ \frac{du}{dt} = g(u,t) \]

\[ \implies \frac{u(t) - u(t - \Delta t)}{\Delta t} \approx g(u,t) \]

\[ \implies u(t) \approx u(t - \Delta t) + \Delta t g(u,t) \]

Let the discretized problem domain be: ${t_0, t_1, t_2, \cdots, t_n}$ and the initial condition be $u(t_0 ) = u_0$

\[ u_1 \approx u_0 + (t_1 - t_0)g(u_1,t_1) \]

\[ u_2 \approx u_1 + (t_2 - t_1)g(u_2,t_2) \]

In general:

\[ u_{i+1} \approx u_{i} + (t_{i+1} - t_{i})g(u_{i+1},t_{i+1}) \]

The value of the function at time $t_{i+1}$ is only known implicitly – thus the name implicit Euler method

Example#

Let us consider the exponential decay problem ($a > 0$ and $t\in(0, T]$)

\[ \frac{du(t)}{dt} = -au(t) \qquad \qquad u(t=0) = u_0\]

Numerical solution using backward Euler method (assuming uniform dicretization)

\[ \frac{du(t_i)}{dt} \approx \frac{u(t_{i}) - u(t_{i-1})}{\Delta t} = -au(t_i) \]

\[ \implies u_i = -a u_i \Delta t + u_{i-1} \]

Shifting the subscript indices by 1 will not affect the above equation:

\[ u_{i+1} = \frac{u_i}{1 + a \Delta t} \]

Again, repeated application of this formula will help solve for $u$ at discrete time points
Such explicit formulae are generally not possible with the backward Euler method
Nonlinear ODE’s result in nonlinear system of algebraic equations
- Can be solved using the Newton’s method

# Problem parameters
a = 1
u0 = 1
T = 5     # Final time

# numerical solution
dt = 0.5                 # Time step
t = np.arange(0, T + dt, dt)  # Time domain
u = np.zeros_like(t)     # Initialize u array
u[0] = u0                # Set initial value

# Compute velocity at discrete time points
for i in range(len(u)-1):
    # Backward Euler formula
    u[i+1] = u[i]/(1 + a*dt)

# Exact solution
t_fine = np.linspace(0, T, endpoint=True)
u_exact = np.exp(-a*t_fine)


fig, ax = plt.subplots()
ax.plot(t, u, '.-k', label='Bkwd. Euler')
ax.plot(t_fine, u_exact, '-k', label='Exact Soln.')
ax.set(xlabel='t (s)', ylabel='u')
ax.legend();

Reduction of Order#

IVPs of order $n$ can be reduced to a system of IVPs of order 1

\[ \frac{d^nf}{dt} = F(t, f, f', f'', \cdots, f^{n-1}) \]

Define a vector S(t) referred to as the state of the system:

\[\begin{split} \begin{gather} S(t) = \begin{pmatrix} S_1(t) \\ S_2(t) \\ S_3(t) \\ ... \\ S_n(t) \end{pmatrix} = \begin{pmatrix} f(t) \\ f'(t) \\ f''(t) \\ ... \\ f^{n-1}(t) \end{pmatrix} \end{gather} \end{split}\]

Taking the derivative of the matrix equation w.r.t. $t$:

\[\begin{split} \begin{gather} \frac{dS}{dt} = \begin{pmatrix} f'(t) \\ f''(t) \\ f'''(t) \\ ... \\ f^{n}(t) \end{pmatrix} = \begin{pmatrix} S_2(t) \\ S_3(t) \\ S_4(t) \\ ... \\ F(t, f, f', f'', ..., f^{n-1}) \end{pmatrix} \end{gather} \end{split}\]

Thus, an IVP of order $n$ is now split into $n$ 1^st order coupled IVPs

\[ \frac{dS_1}{dt} = S_2(t) \]

\[ \frac{dS_2}{dt} = S_3(t) \]

\[ \vdots \]

\[ \frac{dS_n}{dt} = F(t, f, f', f'', ..., f^{n-1}) \]

Second Order Example#

\[ \frac{d^2y}{dt^2} = -g \]

Exact solution: $y(t) = y_0 + v_0t - \frac{1}{2}gt^2$

We can turn this into a system of first order equations ($v = dy/dt$):

\[\begin{split} \begin{gather} S(t) = \begin{pmatrix} S_1(t) \\ S_2(t) \end{pmatrix} = \begin{pmatrix} y \\ v \end{pmatrix} \end{gather} \end{split}\]

\[\begin{split} \begin{gather} \frac{dS}{dt} = \begin{pmatrix} \frac{dy}{dt} \\ \frac{dv}{dt} \end{pmatrix} = \begin{pmatrix} v \\ -g \end{pmatrix} \end{gather} \end{split}\]

These equations can be written in matrix form as:

\[\begin{split} \frac{dS}{dt} = \begin{pmatrix} 0 & 1 \\ 0 & 0 \end{pmatrix} \begin{pmatrix} \frac{dy}{dt} \\ \frac{dv}{dt} \end{pmatrix} + \begin{pmatrix} 0 \\ -g \end{pmatrix} = A(t)S(t) + b(t) \end{split}\]

Separating the equations:

\[\frac{dy}{dt} = v \qquad \frac{dv}{dt} = -g\]

Applying forward difference method:

\[\frac{dy}{dt}\approx\frac{y_{i+1}-y_i}{\Delta t} = v\]

\[\frac{dv}{dt}\approx\frac{v_{i+1}-v_i}{\Delta t} = -g\]

Solving for values at $t_{i+1}$:

\[ y_{i+1} = y_i + \Delta t v_i \]

\[ v_{i+1} = v_i - \Delta t g \]

Find the maximum height of a vertically thrown ball
- $m= 0.1 kg$, $g = 9.81 m/s^2$, $v_0 = 10 m/s$, $y_0 = 0m$

# Problem parameters
m = 0.1  # kg
v0 = 10  # m/s
y0 = 0   # m
g = 9.81 # m/s2

# Numpy arrays for t, y and v
dt = 0.01  # Time step
t = np.arange(0, 1.5, dt)  # Time domain
y = np.zeros_like(t)       # Initialize position array
v = np.zeros_like(t)       # Initialize velocity array

# Set initial height and velocity
y[0] = y0
v[0] = v0

# Numerical solution using foward differencing
for i in range(len(v)-1):
    y[i+1] = y[i] + v[i]*dt
    v[i+1] = v[i] - g*dt

y_max = max(y)
t_max = t[np.argmax(y)]
print(f"The maximum height reached is {y_max:0.2f} m at a time of {t_max:0.2f} s.")

# Plot
fig, ax = plt.subplots()
ax.plot(t, y, '-k', label='Height (m)')
ax.plot(t, v, '-r', label='Velocity (m/s)')
ax.plot(t_max, y_max, 'ob')
ax.set(xlabel=r'$t\ (m)$')
ax.legend();

Python Implementations#

Scipy uses the solve_ivp function to evaluate IVPs using a Runge-Kutta RK45 scheme
Process
- Step 1: Define system with differential equation and initial condition(s)
- Step 2: Isolate the highest derivative on the left hand side
- Step 3: Create state variable, S. For second and higher order ODEs, rewrite the initial ODE in terms of the state variables.
- Step 4: Define a python function whose output is dS/dt
- Step 5: Use scipy.integrate.solve_ivp function

SciPy IVP Examples#

Example 1: First Order, Linear IVP.

\[ \frac{df}{dt} = f + 1 \]

\[ f(t=0) = 5 \]

from scipy.integrate import solve_ivp

# Define state variable from f' = f+1
# function should return right hand side of ODE
def f_prime(t,f):
    return f + 1

# Initial Condition
f0 = [5]

# Define start, stop, and step for time
t_span = [0, 5]
t_step = 0.1
t = np.arange(t_span[0], t_span[1]+t_step, t_step)

# exact solution
f_exact = (f0[0]+1)*np.exp(t) - 1

# Evaluate IVP using solve_ivp
# Arguments are the state function, the time span, initial condition(s), and time domain to solve over
# t_eval is an optional argument. scipy will choose some time step if this is not specified
sol = solve_ivp(f_prime, t_span, f0, t_eval = t)
sol

# use sol.t and sol.y[0] to extract time and function value solutions
fig, ax = plt.subplots()
ax.plot(sol.t, sol.y[0], '-r', label = 'approx')
ax.plot(t, f_exact, '-k', label = 'exact')
ax.legend();

Example 2: First Order, non-linear IVP.

\[ \frac{df}{dt} = f^2cos(f) \]

\[ f(t=0) = 1 \]

# Note there does not exist an analytical solution to this equation. It can only be solved numerically.

# Define state variable from f' = f**2cos(f)
# function should return right hand side of ODE
def f_prime(t,f):
    return f**2*np.cos(f)

# Initial Condition
f0 = 1
t_span = [0,2]

# Evaluate IVP
# Arguments are the state function, the time range, initial condition(s)
sol = solve_ivp(f_prime,t_span,[f0])

# use sol.t and sol.y[0] to extract time and function value solutions
fig, ax = plt.subplots()
ax.plot(sol.t, sol.y[0], '-ok');

Example 3: Second-order, linear IVP

\[ \frac{d^2x}{dt^2} = \frac{dx}{dt} + 2x \]

\[ x(t=0) = 1 \qquad \frac{dx}{dt} = 0 \]

For a second-order ODE, we need to define the state variable, S
$S_0$ is the base function (x in this case), and $S_1$ is the derivative of $S_0$, which we will call $v$ here

Then we need to define $\frac{dS}{dt}$
Rewriting our initial differential equation in terms of $v$ and $x$ gives:

\[ \frac{dv}{dt} = v + 2x \qquad \frac{dx}{dt} = v\]

And we can define the state variable and derivative as:

\[\begin{split} \begin{gather*} S = \begin{pmatrix} x \\ v \end{pmatrix} \qquad \qquad \frac{dS}{dt} = \begin{pmatrix} \frac{dx}{dt} \\ \frac{dv}{dt} \end{pmatrix} = \begin{pmatrix} v \\ v + 2x \end{pmatrix} \end{gather*} \end{split}\]

# The analytical solution to this equation is x(t) = 1/3 e^(-t)[e^(3t)+2]
t_exact = np.linspace(0,1,101)
x_exact = 1/3 * np.exp(-t_exact)*(np.exp(3*t_exact)+2)

# solve_ivp always uses y as the symbol for state variable, instead of S
# you can change all of the y's to s's if it helps
# This function needs to define the two state variables (x,v = y) and return dS/dt as an array
def fun(t, y):
    x, v = y
    dydt = [v, v + 2*x]
    return dydt

tspan = [0, 1]
y0 = [1, 0]  # initial conditions need to be in order of y = [x0, v0]

# solve the IVP. Note that sol.y returns the entire state variable. To extract just x, use sol.y[0]. To extract just v, use sol.y[1]
sol = solve_ivp(fun, tspan, y0)

# the default time step chosen by scipy here seems to be a bit coarse. You may wish to specify a smaller dt (see example 1)
fig, ax = plt.subplots()
ax.plot(sol.t, sol.y[0], '-or', label = 'x')
ax.plot(sol.t, sol.y[1], '-ob', label = 'v')
ax.plot(t_exact, x_exact, '-k', label = 'x_exact')
ax.legend();

Example 4: System of IVPs

\[ \frac{dx_1}{dt} = x_2 \qquad \qquad \frac{dx_2}{dt} = -x_1 - x_2 \]

\[ x_1(0) = 1 \qquad \qquad x_2(0) = 2 \]

A state variable can be defined. In the case of a system of ODEs, each base variable would be one of the state variables.

\[\begin{split} \begin{gather*} S = \begin{pmatrix} x_1 \\ x_2 \end{pmatrix} \qquad \qquad \frac{dS}{dt} = \begin{pmatrix} \frac{dx_1}{dt} \\ \frac{dx_2}{dt} \end{pmatrix} = \begin{pmatrix} x_2 \\ -x_1 - x_2 \end{pmatrix} \end{gather*} \end{split}\]

# there is probably some analytical solution to this in the form of sin and cos, but I don't feel like solving it

# define the state function using the definitions above
def fun(t, y):
    x1, x2 = y
    dx1dt = x2
    dx2dt = -x1 - x2
    return [dx1dt, dx2dt]

t_span = [0, 5]     # time domain
y0 = [1, 2]         # initial conditions
t = np.linspace(t_span[0], t_span[1], 100) # the solution was course, so we can define a more refined domain

sol = solve_ivp(fun, t_span, y0, t_eval = t)

fig, ax = plt.subplots()
ax.plot(sol.t, sol.y[0], '-r', label='$x_1(t)$')
ax.plot(sol.t, sol.y[1], '-b', label='$x_2(t)$')
ax.legend();

Example 5: System of second-order IVPs

\[ \frac{d^2x}{dt^2} = -3x + y \qquad \qquad \frac{d^2y}{dt^2} = -2y + x \]

\[ x(0) = 0 \qquad x'(0) = 1 \qquad y(0) = 1 \qquad y'(0) = 0 \]

We need to convert each of these equations into two first-order equations
We should end up with four state variables
Let us define x’ = u and y’ = v and rewrite our equations in terms of these:

\[ \frac{dx}{dt} = u \qquad \frac{du}{dt} = -3x + y \qquad \qquad \frac{dy}{dt} = v \qquad \frac{dv}{dt} = -2y + x \]

\[ x(0) = 0 \qquad u(0) = 1 \qquad y(0) = 1 \qquad v(0) = 0 \]

Now our state variable can be defined:

\[\begin{split} \begin{gather*} S = \begin{pmatrix} x \\ u \\ y \\ v \end{pmatrix} \qquad \qquad \frac{dS}{dt} = \begin{pmatrix} x' \\ u' \\ y' \\ v' \end{pmatrix} = \begin{pmatrix} u \\ -3x + y \\ v \\ -2y + x \end{pmatrix} \end{gather*} \end{split}\]

# define the state function based on the work above
# s = [x, u , y, v]
def fun(t, y):
    x, u, y, v = y
    dxdt = u
    dudt = -3*x + y
    dydt = v
    dvdt = -2*y + x
    return [dxdt, dudt, dydt, dvdt]

# Define initial conditions (must be in the same order as in the state function s0 = [x0, u0, y0, v0]
y0 = [0, 1, 1, 0]

# Define time span
t_span = [0, 10]
t = np.linspace(t_span[0], t_span[1], 100) # the solution was course, so we can define a more refined domain

# Solve the system of ODEs
sol = solve_ivp(fun, t_span, y0, t_eval = t)

fig, ax = plt.subplots()
ax.plot(sol.t, sol.y[0], '-r', label='$x(t)$')
ax.plot(sol.t, sol.y[2], '-b', label='$y(t)$')
ax.legend();

Example 6: Projectile Motion

\[ \frac{d^2y}{dt^2} = -g \]

Define $\frac{dy}{dt} = v$

\[ y_0 = 0 m \qquad v_0 = 10 m/s \]

Our state variable is:

\[\begin{split} \begin{gather*} S = \begin{pmatrix} y \\ v \end{pmatrix} \qquad \qquad \frac{dS}{dt} = \begin{pmatrix} y' \\ v' \end{pmatrix} = \begin{pmatrix} v \\ -g \end{pmatrix} \end{gather*} \end{split}\]

m = 0.1  # kg
g = 9.81  # m/s^2
v0 = 10  # m/s
y0 = 0  # m

# note solve_ivp uses the variable y for the state
# Define the state equation, y[0] is position and y[1] is velocity
# thus dy/dt = [v, -g]
def f(t, y):
    v = y[1]
    return [v, -g]

t_span = [0, 2.1]  # Solve up to t = 2.1s
t = np.linspace(t_span[0], t_span[1], 1000)

sol = solve_ivp(f, t_span, [y0, v0], t_eval=t)

# Find the maximum height
max_height = np.max(sol.y[0])

print("Maximum height:", max_height)

# Create subplots for position and velocity
fig, (ax1, ax2) = plt.subplots(2, 1, figsize=(8, 8))

# Plot position vs time
ax1.plot(sol.t, sol.y[0], label="Position")
ax1.set_ylabel("Position (m)")
ax1.set_ylim(0)
ax1.set_title("Ball trajectory")

# Plot velocity vs time
ax2.plot(sol.t, sol.y[1], label="Velocity")
ax2.set_xlabel("Time (s)")
ax2.set_ylim(-10)
ax2.set_ylabel("Velocity (m/s)")

plt.tight_layout();

Boundary Value Problems#

A BVP constitutes:
- A differential equation that is valid in the interval $a < x < b$
- Boundary conditions (BCs)
  - The function and some of the lower order derivative at the extremes $x = a$ and $x = b$

\[ \frac{d^n f(x)}{dx^n} = F(x, f(x), f'(x), f''(x), \cdots, f^{n-1}(x)) \]

Example: steady state heat transfer via conduction across a rod is described by a second order BVP

\[ \frac{d^2T}{dx^2} = 0 \]

Boundary conditions: either temperature, $(T)$, or heat flux, $\left(-k\frac{dT}{dx}\right)$, is required at $x = a$ and $x = b$

Boundary Conditions#

There are several types of boundary conditions
- Dirichlet - the function value is known at the boundary
  - e.g., $T(x = a) = T_a$ or $T(x = b) = T_b$

Neumann - the function derivative value is known at the boundary
- e.g., $\frac{dT}{dx}|_{x = a} = C_a$ or $\frac{dT}{dx}|_{x = b} = C_b$

Robin - some combination of function and derivative value is known at the boundary
- e.g., $c_0 T + c_1 \frac{dT}{dx}|_{x = a} = C_a$

A BVP can specify only Dirichlet, Neumann, or Robin boundary conditions at both boundaries or some combination of them

Solution methods for BVPs
- The shooting method
- Finite difference method (FDM)
- Finite element method (FEM)
- $\cdots$

Finite difference method
- Discretize the problem domain into $n$ sub-domains
- Use finite difference approximation to approximate the derivatives
- This converts the differential equation (and BCs) into a difference equation at each discrete point in the discretized domain
- Solve the system of linear equations to obtain the unknown 𝑦 values

Example: Projectile Motion#

Projectile moves purely in the vertical direction under gravity

\[ \frac{d^2y}{dt^2} = -g \]

To be a BVP (and not an IVP) we need to know the value of y at the initial time and the final time

\[ y(t=0s) = 0m \qquad y(t=5s) = 50m \]

Assume a uniform discretization of the problem domain $t\in(0, 5)$ into $n$ intervals

Central difference approximation of the second derivative

\[\frac{d^2y}{dt^2} |_{t=t_i} \approx \frac{y_{i+1} - 2y_i + y_{i-1}}{\Delta t^2}\approx -g\]

At time $t=t_i$, the ODE is now transformed to:

\[ y_{i+1} - 2y_i + y_{i-1} = -g\Delta t^2 \]

A step size must be chosen. Let’s pick a total of 4 nodes to sovle over $i = [0, 1, 2, 3]$ and $\Delta t = 5/3$

Using the FD equation at the interior points:

\[\begin{split} \begin{align*} &i = 0:& y_0 &= 0 & \text{Left BC} \\ &i = 1:& y_2 - 2y_1 + y_0 &= -g\Delta t^2 &\\ &i = 2:& y_3 - 2y_2 + y_1 &= -g\Delta t^2 &\\ &i = 3:& y_3 &= 50 &\text{Right BC} \end{align*} \end{split}\]

This is a solvable linear system of equations (4 equations, 4 unknowns). We can use linear algebra to evaluate.

As discussed previously, we can turn this system into a matrix equation.

\[\begin{split} \begin{gather} \begin{bmatrix} 1 & 0 & 0 & 0 \\ 1 & -2 & 1 & 0 \\ 0 & 1 & -2 & 1 \\ 0 & 0 & 0 & 1 \end{bmatrix} \begin{pmatrix} y_0 \\ y_1 \\ y_2 \\ y_3 \end{pmatrix} = \begin{pmatrix} 0 \\ -g\Delta t^2 \\ -g\Delta t^2 \\50 \end{pmatrix} \end{gather} \end{split}\]

If we generalized this to $n$ points (instead of 3):

\[\begin{split} \begin{gather} \begin{bmatrix} 1 & 0 & 0 & 0 & \ldots & 0 \\ 1 & -2 & 1 & 0 & \ldots & 0\\ 0 & 1 & -2 & 1 & \ldots & \vdots \\ \vdots & \ddots & \ddots & \ddots & \ddots & 0 \\ \vdots & \ldots & 0 & 1 & -2 & 1 \\ 0 & \ldots & 0 & 0 & 0 & 1 \end{bmatrix} \begin{pmatrix} y_0 \\ y_1 \\ y_2 \\ \vdots \\ y_{n-1} \\ y_n \end{pmatrix} = \begin{pmatrix} 0 \\ -g\Delta t^2 \\ -g\Delta t^2 \\ \vdots \\ -g\Delta t^2 \\ 50 \end{pmatrix} \end{gather} \end{split}\]

The finite difference method leads to a linear system with a sparse, banded coefficient matrix
- Sparse linear system solvers are more efficient

from scipy.sparse.linalg import spsolve

# Problem parameters
g = 9.81       #m/s2
ta, tb = 0, 5  #s
ya, yb = 0, 50 #m

#exact solution
t_exact = np.linspace(ta, tb, 100)
y_exact = 0.5*t_exact*(20 - g*(t_exact - 5))

#FDM solution
n = 4  # Number of Nodes
dt = (tb-ta)/(n-1)  #time step, s. There are n-1 divisions if there are n nodes
t = np.linspace(ta, tb, n)  #define domain

# Define A matrix
A = np.zeros([n,n]) #initialize size with all zero values
# First and last rows defined by BCs.
A[0,0] = 1
A[-1,-1] = 1
# loop over each internal row. Don't include first or last point in range
for i in range(1, n-1):
    A[i,[i-1,i,i+1]] = np.array([1,-2,1])

# define b matrix
# First and last rows defined by BCs.
b = -g*dt**2*np.ones(n)
b[0] = ya
b[-1] = yb

# Matrix Equation Ay = b
# use sparse linalg solver on matrix equation
sol = spsolve(A, b)

# plot results
fig, ax = plt.subplots()
ax.plot(t, sol, '-or', markersize = 4, label = 'FDM')
ax.plot(t_exact, y_exact, '-b', label = 'Exact')
ax.legend()
ax.set_xlabel('Time (s)')
ax.set_ylabel('Height (m)');

Solving BVPs Using Scipy#

The scipy function solve_bvp from scipy.integrate can more readily package and solve BVPs.
- Uses a collocation method (don’t worry about it)
- The output of solve_bvp is a lit of piecewise-polynomial interpolations of the solution

Example: Steady Heat Conduction with Dirichlet BC’s#

\[ k \frac{d^2T}{dx^2} = -s\]

\[T(x = a) = T_a \qquad \qquad T(x=b) = T_b\]

$k$ is thermal conductivity and $s$ is heat generated per unit volume

State Equation: let $\frac{dT}{dx} = q$

\[\begin{split} \begin{gather*} S = \begin{pmatrix} T \\ q \end{pmatrix} \qquad \qquad \frac{dS}{dt} = \begin{pmatrix} \frac{dT}{dx} \\ \frac{dq}{dx} \end{pmatrix} = \begin{pmatrix} q \\ -s/k \end{pmatrix} \end{gather*} \end{split}\]

from scipy.integrate import solve_bvp

# Define parameters and BCs
k = 1
s = 20 # Heat source divided by k
xa, xb = 0, 2
Ta, Tb = 50, 50

# state function, S = [T, q]. Must output dS/dt = [q, C]
# there are some very specific rules about how to structure the output. Be very careful.
def fun(t, S):
    T, q = S
    # each of these terms MUST be an array of the same size. Use np.zeros_like or np.ones_like for constants
    dTdx = q
    dqdx = -s*np.ones_like(dTdx)/k

    # The matrix solver expects the state derivative function to be vertical.
    # The easiest way to do this is use np.vstack on the horizontal array
    return np.vstack([dTdx, dqdx])

# Need to define boundary conditions within a function
# Sa and Sb refer to the left and right boundaries, respectively
# The [0] or [1] index refer to T and q, respectively
# Note the sign flip on the BC definitions. This is due to solving for zero in the BC equations.
def bc(Sa, Sb):
    bc1 = Sa[0] - Ta
    bc2 = Sb[0] - Tb
    return np.array([bc1, bc2])

# define a domain to solve over.
x = np.linspace(xa, xb, 50)
S = np.zeros((2, x.size))  # the first arguement is the number of elements in the state variable

# Solve the BVP
sol = solve_bvp(fun, bc, x, S)
x = sol.x
T = sol.y[0]
q = sol.y[1]

# solve_bvp uses y as the name of the state variable
# T is stored in y[0]. q = dT/dx is stored in y[1]
fig, ax = plt.subplots()
ax.plot(x, T, '-r')
ax.set_xlabel('x (m)')
ax.set_ylabel('T ($\degree$C)');

Example: Projectile Motion with mixed BC’s#

\[ \frac{d^2x}{dt^2} = 0 \qquad \qquad \frac{d^2y}{dt^2} = -g \]

Define: $\frac{dx}{dt} = \dot{x}$ and $\frac{dy}{dt} = \dot{y}$. State Equation:

\[\begin{split} \begin{gather*} S = \begin{pmatrix} x \\ \dot{x} \\ y \\ \dot{y} \end{pmatrix} \qquad \qquad \frac{dS}{dt} = \begin{pmatrix} \dot{x} \\ \ddot{x} \\ \dot{y} \\ \ddot{y} \end{pmatrix} = \begin{pmatrix} \dot{x} \\ 0 \\ \dot{y} \\ -g \end{pmatrix} \end{gather*} \end{split}\]

BCs: $$\dot{x}(t=0s) = 10 m/s \qquad y(t=0s) = 0m \qquad x(t=2s) = 5m \qquad \dot{y}(t=2s) = -5 m/s$$

# Define parameters and BCs
g = 9.81                 # m/s2
t_start, t_stop = 0, 2   # s
dxdt0 = 10              # m/s
y0 = 0                   # m
x2 = 5                   # m
dydt2 = -5               # m/s

# state function, S = [x, u, y, v]. Must output dS/dt = [u, 0, v, -g]
# there are some very specific rules about how to structure the output. Be very careful.
def fun(t, S):
    x, dxdt, y, dydt = S
    # each of these terms MUST be an array of the same size. Use np.zeros_like or np.ones_like for constants
    d2xdt2 = np.zeros_like(x)
    d2ydt2 = -g*np.ones_like(x)
    # The matrix solver expects the state derivative function to be vertical.
    # The easiest way to do this is use np.vstack on the horizontal array
    return np.vstack([dxdt, d2xdt2, dydt, d2ydt2])

# need to define boundary conditions within a function
# Sa and Sb refer to the left and right boundaries, respectively.
# Use the same indicies as defined by state variable [x, u, y, v]
# Note the sign flip on the BC definitions. This is due to solving for the other side of the BC equation
def bc(Sa, Sb):
    bc1 = Sa[1] - dxdt0
    bc2 = Sb[0] - x2
    bc3 = Sa[2] - y0
    bc4 = Sb[3] - dydt2
    return np.array([bc1, bc2, bc3, bc4])

# define a domain to solve over.
t = np.linspace(t_start, t_stop, 20)
S = np.zeros((4, t.size))   # the first arguement is the number of elements in the state variable

sol = solve_bvp(fun, bc, t, S)

# create plots
fig, ax = plt.subplots()
ax.plot(sol.y[0], sol.y[2], '-b')
ax.set_xlabel('x (m)')
ax.set_ylabel('y (m)');

fig, ax = plt.subplots()
ax.plot(t, sol.y[0], '-b', label = '$x$')
ax.plot(t, sol.y[1], '-r', label = '$\dot{x}$')
ax.plot(t, sol.y[2], '--b', label = '$y$')
ax.plot(t, sol.y[3], '--r', label = '$\dot{y}$')
ax.axhline(0, ls='-', color='k', lw=1)
ax.legend()
ax.set_xlabel('t (s)');

Partial Differential Equations#

PDEs involve partial derivatives

Any problem in which parameters can vary in more than one of time or the three spatial dimensions must be modeled as a PDE
- Many real-world problems are best modeled with PDEs
- ODEs are still useful in modeling specialized or simplified problems

While the finite difference method can be used to solve PDEs with simple domains, finite element or finite volume methods are more popular
- In ME 313 - Engineering Analaysis, you will learn finite element method to solve structural engineering problems

If you need to solve a PDE in the future, search for algorithms or modules for the specific type of problem you are solving
- 2D transient heat diffusion
- Viscous, unsteady pipe flow

Many common types of physics have specialized software packages
- Structural mechanics in Solidworks (rudimentary), Ansys, Abaqus, Comsol, etc.
  - Use the finite element method
- Fluid or thermofluid problems in Ansys Fluent, Star-CCM+, OpenFoam, etc.
  - Known as computational fluid dynamics (CFD) packages and predominantly use the finite volume method

Solving ODEs

Contents

Solving ODEs#

Differential Equations#

Ordinary Differential Equations#

Initial Value Problems#

Forward Euler Method#

Example#

Backward Euler Method#

Example#

Reduction of Order#

Second Order Example#

Python Implementations#

SciPy IVP Examples#

Boundary Value Problems#

Boundary Conditions#

Example: Projectile Motion#

Solving BVPs Using Scipy#

Example: Steady Heat Conduction with Dirichlet BC’s#

Example: Projectile Motion with mixed BC’s#

Partial Differential Equations#

Further Reading#
